REPORT HIGHLIGHTS

• The estimated volume volume of research based on nanotubes (both single wall and specialty multiwall nanotubes) that have been produced worldwide to date, range from 10 to 20 kg, with a value of approximately $5 to $10 million. This report uses a figure of 22.1 kg in 2002, with a value of $7.2 million.
• Multiwall nanotubes for modifying polymers are now sold in million-pound plus quantities.
• Nanotubes may see near-term use in military, consumer and industrial products.
• Long-term applications of nanotubes can easily exceed several billion dollars, but when, is debatable.

REPORT SCOPE

INTRODUCTION

OBJECTIVE AND PURPOSE OF THIS REPORT

This report focuses on carbon nanotubes — their technology, production, and applications. There has been enormous interest in the commercialization of nanotubes for both near and distant applications, and several of these applications will be successful shortly.

Nanotubes, cylinders of carbon atoms with diameters ranging from less than 1 to 300 nanometers (nm), are some of the strongest, stiffest materials known. Furthermore, these materials are either conductors or semi-conductors, depending on their structure and environment. Nanotubes have some physical properties that have no counterpart in macroscopic materials.

With advances in synthetic techniques and the ability to characterize materials readily on an atomic scale, interest has been piqued in nanometer-size materials. Since nanometer-size grains, cylinders, and plates have dramatically larger surface areas compared to their conventional-size materials, the chemistry of these nano-size materials is altered compared to that of conventional materials.

Macroscopic carbon compounds, such as diamond and graphite, have been known for centuries. These two forms of carbon compounds have been used in various applications, ranging from lubricants to wear-resistant coatings. Although these materials have been available for many years, new applications of these materials are still being discovered today. It is clear that both graphite and diamond are economically important materials.

For many years, it was thought that graphite and diamond represented the only two stable forms of carbon-only compounds. Thus, it came as quite a surprise when Richard Smalley and coworkers at Rice University announced the discovery of a new form of carbon compound in 1985. These carbon compounds were called "fullerenes," or "buckyballs," after Buckminster Fuller. Buckminster Fuller is best known for developing the geodetic dome, and the new carbon compounds greatly resembled these domes, albeit at an atomic level. The first fullerenes to be characterized consisted of 60 carbon atoms arranged like a soccer ball.

Since the two known forms of carbon, diamond and graphite, have proven to be very useful materials, it was hoped that fullerenes would prove valuable as well. Unfortunately, although these compounds stirred a great deal of interest, their primary value to date has been to academic researchers, who have received innumerable grants to study these compounds. No applications to take advantage of the structures of these molecules have been developed, although there is still a great deal of research being carried out on drug delivery systems.

In the past decade, Iijima at NEC discovered a similar type of molecule, a fullerene that is cylindrical rather than spherical. These cylindrical fullerenes have a much wider range of potential applications compared to the spherical molecules, and already these compounds have been used in some limited applications.

While it is impossible to make a wire out of a sphere, cylinders are another matter. Characterization of the fullerene cylinders, soon termed "nanotubes," showed that there was a range of conductivities of these molecules. Therefore, it was theoretically possible to use nanotubes to produce wires that were orders of magnitude smaller and lighter than anything previously technologically possible. Cylinders can also be used to make fibers or construct weaves or mesh ¾ something that cannot be accomplished with spheres. Thus, nanotubes are really much more versatile than the first buckyballs, and are being studied for a much broader range of applications.

This report summarizes the status of nanotube production and technology. It also covers the applications for these nanotubes and estimates their possible future markets. Armed with this information, readers with interests can make sound judgements regarding marketing strategies, investment decisions, or strategic plans concerning the market for nanotubes. This report has been written to be readily accessible for those readers with a background, but accuracy concerning the technical aspects of nanotube manufacture and applications has not been sacrificed.

REASONS FOR THIS STUDY

While there has been much ballyhoo in the popular press concerning the wonders of nanotubes, it is difficult to get solid information on how much of these nanotubes are being produced and sold. Furthermore, many articles have presented wildly misleading information concerning these materials' manufacture, markets, and applications. This report offers a timely picture of trends for nanotubes that cannot be obtained from other sources.

CONTRIBUTIONS THE STUDY

This report shows the current (small) and future sizes of the nanotube markets in the U.S. and globally. Since research on nanotubes is being done worldwide, this report covers developments in all regions of the world. However, there are large sums of money being appropriated for nanotube research by Congress; therefore, the U.S. will be one of the countries at the forefront of nanotube research and development for some years to come. Readers of this report will be able to distinguish the hype concerning the uses of nanotubes from the reality of the market. A number of the potentially significant markets of nanotubes have received relatively little press, and many of the published articles concerning the uses of these materials do not provide an accurate picture. This report will also show what applications are achievable without any new breakthroughs in the production methodology of nanotubes, and what applications require nanotubes to be produced much less expensively.

SCOPE AND FORMAT

In order to generate the information necessary to construct a reasonable future market for nanotubes, it is necessary to take a hard-headed look at the potential advantages and pitfalls of these materials. However, given the novel applications of nanotubes, it can be difficult to compare them to more conventional macroscopic materials. Furthermore, nanotubes do offer the possibility of revolutionary, rather than evolutionary, developments in many product applications.

While many applications of nanotubes are clearly not going to happen in the next decade (especially the highly touted replacement of silicon in transistors in integrated circuits), this does not mean that there will be no applications of nanotubes in other markets. This report therefore focuses on the near-term potential applications of nanotubes, rather than applications requiring major technological leaps, such as micro-electromechanical (MEM) applications or other transistor applications. Therefore, this report focusses on applications of nanotube materials that are possible within the next five to 10 years.

The report is broken into six sections. First, there is a technology overview, which gives the broad details of nanotubes, along with some of their physical properties and methods of manufacture. Next, there is an extensive description of the industry, which is developing the manufacturing capability for nanotubes. Firms that are developing applications for nanotubes include automotive manufacturers, chemical firms, electronic manufacturers, display firms, and others. These firms are described in the section on company profiles. Following this section on industry structure is a brief description of the government and academic laboratories that have been doing extensive research in nanotubes. Next we have a description of nanotubes by type, followed by a description of the markets for nanotubes, including future trends. The report concludes with a brief section on the rise in nanotube patents filed over the past few years.to date.

METHODOLOGY AND SOURCES OF INFORMATION

This report is the result of three months of concerted effort by the author, but also builds on a previous report written two years ago on this topic. The primary sources of information for writing this report are interviews with several dozen peoplein industry, academia, and the government. The author also attended meetings and conferences and gained much precious insight from these sources as well. Many of the people interviewed are recognized authorities in the field and provided invaluable assistance. The author would like to thank all who took the time to offer their help with this project. Secondary sources used for this report include a number of publications by the Federal government, plus items gleaned from the Internet, corporate literature, and publications in peer-reviewed literature.

Any time an estimate for a number has been made, the underlying assumptions are discussed. Thus, if the reader chooses to interpret the raw data in a different manner, it is possible to do so. Dollar amounts are in constant 2001 dollars, and average annual growth rates (AAGRs) are calculated using standard tables.

AUTHOR'S CREDENTIALS

The author has published over 10 reports with Communications Co., Inc. (BCC), several of which related directly to this report. The author has also performed custom studies for BCC, presented original research to corporate clients, and holds a Ph.D. in inorganic chemistry. His past research activities include the formation of chromium complexes in an interdisciplinary group. The author is also a member of SAMPE (Society for the Advancement of Material and Process Engineering).

RELATED REPORTS

• GB-154R Smart Materials: A Market and Technology Assessment
• NAN017A Opportunities in Nanostructured Materials
• SMC051A MEMS Technology: Where To?
• SMC037B Sputtering Targets and Sputtered Films: Technology and Markets
• AVM025D Diamond, Diamond-like And CBN Films and Coated Products: Market Analysis
• AVM025E Diamond, Diamond-like Carbon/CBN Films and Coated Products: Technology Analysis
• SMC049A Flexible Circuits: Where To?
• AVM027B Iron and Iron-Oxide Powders: Trends and Markets
• AVM016D Sol Gel Processing of Ceramics and Glass
• AVM038A Advanced Structural Carbons: Fibers, Foams, and Composites
• SMC047A New Chips for New Applications
• SMC045A Photonic Integrated Circuits
• SMC027D Thin Layer Deposition: Highlighting CVD — Updated Edition
• SMC027E Thin Layer Deposition: Highlighting PVD— Updated Edition
• SMC027F Thin Layer Deposition: Highlighting Ion Implantation and Epitaxy
• AVM034A Organics for Electro-Optical Applications

REPORT TOC
